Product Description
MSD Ignition Controller, Power Grid, Digital, CD Ignition, 50000V, Rev Limiter, Each
(Ignition Box, Power Grid 7, Capacitive Discharge, Digital, Universal - Designed for Use With Power Grid Controller PN 7730 or 77303 ONLY)
- MSD Power Grid System Programmable Controller NOT INCLUDED
MSD Power Grid 7 Ignition Boxes:
MSD offers these Power Grid 7 ignition boxes as part of the Power Grid 7 ignition system. These ignition boxes pack higher output than other current programmable units. When used with the Power Grid 7 system controller, these USB-compatible boxes offer advanced programming for ultimate control over your rpm and timing. They provide five retard stages for nitrous and four steps of rpm limits for burnouts, spool, launch, and overrev. MSD Power Grid 7 ignition boxes' output switch can be set on rpm, pressure, or time. Power Grid 7 ignition boxes have shift light settings for each gear, and the ignition data acquisition accepts multiple runs.
Features:
- For use with Power Grid PN 7730 or PN 77303 only
- High output spark for Power Grid System
- Power Grid PN 7730/77303 mounts directly on top
| Current Draw | 1.3 Amp per 1,000 RPM |
|---|---|
| Emission Code | 4 |
| Primary Voltage | 545-570 Volts |
| Product Type | Power Grid Controller |
| RPM Range | 15,000 RPM with 14.4 Volts |
| Secondary Voltage | 50,000 Volts |
| Spark Energy | 200-220 mJ per spark |
| Voltage Required | 12-18 Volts, Negative Ground |
